TLV JF5X Flanged Free Float Steam Trap

  • Free Float Mechanical Steam Trap
  • Ductile Iron body
  • Flanged end connection
  • Sizes ¾” to 2”
  • Differential pressures up to 2, 5, 8, 10 and 13 BarG
  • Discharge Capacities up to 1000kg/h
  • Built in Strainer and Thermostatic Air Vent
From £438.00
SKU: ST5311 Availability: Available
In stock
SKU ST5311

TLV JF5X Flanged Free Float Steam Trap

The Free Float design of the JF5X Steam Trap offers advantages over traditional float and bucket style mechanical steam traps offering increased lifetime and efficiency. The integral strainer and thermostatic air vent protects the equipment from particulate and increases productivity by removing hot and cold air from the system.

Suitable for condensate discharge requirements up to 1000kg/h and differential pressures up to 2, 5, 8, 10 and 13 BarG. Maximum operation pressure of 13 BarG and temperature of 200°C combined with the Free Float functionality mean the JF5X is suitable for a wide variety of process uses including cooking/heating vessels, autoclaves and heat exchangers. Available with Ductile Iron Body, Stainless Steel internals and Flanged end connections.

Key features:

  • Ductile iron Body and Stainless Steel internal wetted components.
  • Flanged connections: ¾”, 1”, 1 ¼”, 1 ½” and 2”.
  • Built in Strainer and Thermostatic Air Vent.
  • Free Float Continuous Discharge Mechanical Steam Trap.
  • Max Operating Pressure: 13 BarG.
  • Max Operating Temperature: 200°C.
  • Discharge Capacities up to 1000kg/h.

Download our technical PDF datasheet for the TLV JF5X Flanged Free Float Steam Trap.

More Information
Category Free Float
Function/Use Process
Capacity 760kg/h to 1060kg/h
End Connection Flanged
Body Material Ductile Iron
Size 3/4", 1", 1 1/4", 1 1/2", 2"
Manufacturer TLV

The following downloads are available for the TLV JF5X Flanged Free Float Steam Trap:

TLV JF5X Flanged Free Float Steam Trap Datasheet
