Spirax Sarco PF6 Angle Seat Piston Valve BSP - Normally Closed
SKU
PF6101
£294.42
Available to Order
Compatible file extensions to upload:
Key Features
- Spriax Sarco PF6
- Stainless Steel Body
- Sizes: 1/2” to 2”
- Screwed BSP
- Normally Closed
- Flow over the Seat
- PTFE Stem Seals
- Temperature Range: -10°C to 180°C
Details
Spirax Sarco PF6 Angle Seat Piston Valve BSP - Normally Closed
This Spirax Sarco PF6 Angle Seat Piston Valve is a 2-port pneumatically actuated on/off stainless steel valve for use on steam, water, oil and gases.
Available in sizes 1/2” to 2” with screwed BSP end connections, this normally closed version is designed for flow over the seat (port 1 to 2).
KEY FEATURES:
- Spriax Sarco PF6
- Stainless Steel Body
- Sizes: 1/2” to 2”
- Screwed BSP
- Normally Closed
- Flow over the Seat
- PTFE Stem Seals
- Temperature Range: -10°C to 180°C
Technical Attributes
| Media | Steam, Gas, Liquid |
|---|---|
| Body Material | Stainless Steel |
| Function | Normally Closed |
| End Connection | BSP |
| Size | 1/2" (DN15), 3/4" (DN20), 1" (DN25), 1 1/4" (DN32), 1 1/2" (DN40), 2" (DN50) |
| Manufacturer | Spirax Sarco |
| Main Features |
|
Valve Sizing | Flow Rate (Kv)
| Model | Valve Size | KVs | Actuator Diameter |
Flow direction (port 1 to 2) |
Maximum differential pressure | Pilot Pressure | Pilot Connection | |||||
|---|---|---|---|---|---|---|---|---|---|---|---|---|
| Minimum | Maximum | |||||||||||
| mm | inches | bar | psi g | bar | psi g | bar | psi g | |||||
| PF61G-1NC | DN15 - (½") | 4.5 | 45 | 1.77 | over seat | 16 | 230 | 1.8 | 26 | 10 | 150 | 1/8" BSP |
| DN20 - (¾") | 8.0 | |||||||||||
| PF61G-2NC | DN15 - (½") | 4.5 | 63 | 2.48 | over seat | 20 | 290 | 3.9 | 57 | 10 | 150 | 1/4" BSP |
| DN20 - (¾") | 8.0 | 4.6 | 67 | 10 | 150 | |||||||
| DN25 - (1") | 15.6 | 5.2 | 75 | 10 | 150 | |||||||
| DN32 - (1¼") | 24.6 | 16 | 230 | 5.7 | 83 | 10 | 150 | |||||
| DN40 - (1½") | 42.0 | 8.8 | 128 | 10 | 150 | |||||||
| DN50 - (2") | 57.0 | 11 | 160 | 7.8 | 113 | 10 | 150 | |||||
| PF61G-3NC | DN25 - (1") | 15.6 | 90 | 3.54 | over seat | 20 | 290 | 3.0 | 44 | 8 | 115 | 1/4" BSP |
| DN32 - (1¼") | 24.6 | 16 | 230 | 3.0 | 44 | 8 | 115 | |||||
| DN40 - (1½") | 42.0 | 4.0 | 58 | 8 | 115 | |||||||
| DN50 - (2") | 57.0 | 5.8 | 84 | 8 | 115 | |||||||
