Burkert Type 6213 EV Stainless Steel Solenoid Valve

SKU
BS6213

1 - 2 Weeks

Key Features
  • Servo assisted, 2/2 way with diaphragm
  • Stainless Steel body
  • FKM, NBR or EPDM seals
  • Sizes G 3/8 to G 2
  • Media temperature: 0°C to +90°C
  • Pressure range: 0-10 Bar
  • Voltage: 24V DC, 24V AC and 230V AC
  • Suitable for liquids; including neutral fluids, water and hydraulic oil
  • Best Price Online

Details

Burkert Type 6213 EV Stainless Steel Solenoid Valve

The Burkert Type 6213 EV Stainless Steel Solenoid Valve is a servo-assisted 2/2 way, normally closed solenoid valve for liquids; including neutral fluids, water, hydraulic oil, oil without additives, per-solutions and hot oils with additives using FKM seals. A minimum pressure of 0.1 bar differential is required to open fully.

In addition, the standard Brass housing satisfies all European drinking water requirements. Drinking water approved to KTW / W270.

Key features:

  • Available in Stainless Steel, sizes: G 3/8 to G 2.
  • Seal material: FKM, NBR or EPDM.
  • Voltage: 24V DC, 24V AC and 230V AC.
  • Media temperature: 0°C to +90°C FKM.
  • Ambient temperature: +55°C.
  • Pressure range: 0-10 Bar.

110V AC version available to order upon request.

Datasheet:

 Burkert Type 6213 EV Stainless Steel Solenoid Valve Datasheet

Technical Attributes

Process / Industry General Purpose
Body Material Stainless Steel
Design 2 Way
Function Normally Closed
Port Size G3/8, G1/2, G3/4, G1, G1 1/4, G1 1/2, G2
Seal Material NBR, FKM, EPDM
Voltage 24V DC, 24V AC, 230V AC
Manufacturer Burkert
