PN40 Stainless Steel ARI FABA Plus Globe Isolation Valve

SKU
GV5414

in-stock Available to Order

Key Features
  • PN40 Stainless Steel ARI FABA Plus Globe Isolation Valve
  • Fig. 55.046 Stop Valve with Bellows Seal
  • PN40 Flanged Connection
  • Stainless Steel (1.4408) Body
  • Up to 400°C Temperature Rated
  • DN15 to DN150 (½” to 6”) Available

Details

PN40 Stainless Steel ARI FABA Plus Globe Isolation Valve

The ARI FABA-Plus Stop valve is ideal for isolation duties requiring bellows seals for maintenance free operation.

Suitable for industrial uses in applications such as recycling facilities, chemical industries, hospitals, process water installations for mediums such as steam, process water, air and oil. Stainless Steel construction means that even mildly aggressive applications are suitable.

Non-Rising Handwheel operated, with flanged connections, double wall bellows seal, plug with marginal seat and a bonnet optimised for accessories.

Options available upon request include angle pattern bodies, flanges according to ANSI, regulating plugs, open & close limit switches and PTFE seats.

Key Features:

  • Stop Valve
  • Double Wall Bellows Seal
  • PN40 Flanged Connection
  • Stainless Steel (1.4408) Body
  • Up to 400°C Temperature Rated
  • DN15 to DN150 (½” to 6”)

Datasheet:

 PN40 Stainless Steel ARI FABA Plus Globe Isolation Valve Datasheet

Technical Attributes

End Connection Flanged PN40
Body Material Stainless Steel
Size 1/2" (DN15), 3/4" (DN20), 1" (DN25), 1 1/4" (DN32), 1 1/2" (DN40), 2" (DN50), 2 1/2" (DN65), 3" (DN80), 4" (DN100), 5" (DN125), 6" (DN150)
Design Bellows Sealed, Handwheel Non Rising Stem
Industry / Approvals High Temperature
Manufacturer ARI-Armaturen
