Mars Ball Valve Series 33 3 Way Full Bore Direct Mount

SKU
BV5130

in-stock Available to Order

Key Features
  • Mars Ball Valve Series 33 3 Way Full Bore Direct Mount
  • For general and industrial chemical applications
  • Body material: Stainless Steel
  • End connection: Screwed BSP, Socket Weld, Butt Weld or NPT
  • Three way, L or T port, full bore
  • Reinforced PTFE seat and ISO mounting top for actuation
  • Sizes: 1/4" to 4"
  • Temperature range: -20 °C to 200°C.
  • Operating pressure: 1/4" to 1" 1000 PSI, 1 1/4" to 2" 800 PSI and 2 1/2" to 4" 600 PSI

Related Products

Stainless Steel Y Type Strainer Screwed
Stainless Steel Y Type Strainer Screwed
£22.87
View Product
Stainless Steel Swing Check Valve Screwed BSP
Stainless Steel Swing Check Valve Screwed BSP
£30.49
View Product
Stainless Steel Pressure Reducing Valve
Stainless Steel Pressure Reducing Valve
£256.12
View Product
Mars Series 33 Ball Valve Repair Kit
Mars Series 33 Ball Valve Repair Kit
£31.12
View Product

Details

Mars Ball Valve Series 33 3 Way Full Bore Direct Mount

Our Mars Ball Valve Series 33 3 Way Full Bore Direct Mount provides safe operation for both general and industrial chemical applications, offering superior performance and reliability. A 3 way full bore valve with Stainless Steel body, reinforced PTFE seat and ISO mounting top for actuation.

Features live-loaded chevron PTFE gland packing.

Key features:

  • Available in Screwed BSP, Socket Weld, Butt Weld or NPT: 1/2" to 4".
  • Temperature range: -20 °C to 200°C.
  • Operating pressure: 1/4" to 1" 1000 PSI, 1 1/4" to 2" 800 PSI and 2 1/2" to 4" 600 PSI.
  • Insulated grip, lockable lever handle.
  • Movement: 90° turn.
  • Ports: L or T port.

Investment cast with low torque.

Datasheet:

 Mars Ball Valve Series 33 3 Way Full Bore Direct Mount Datasheet

Technical Attributes

End Connection BSP, NPT, Socket Weld, Butt Weld OD
Body Material Stainless Steel
Seat Material Reinforced PTFE
Size 1/4" (DN8), 3/8" (DN10), 1/2" (DN15), 3/4" (DN20), 1" (DN25), 1 1/4" (DN32), 1 1/2" (DN40), 2" (DN50), 2 1/2" (DN65), 3" (DN80), 4" (DN100)
Design 3 Way, Full Bore
Industry / Approvals General / Industrial / Process
Lever Lockable Manual Lever
Temperature Range -20 °C to 200°C
Pressure Up to: 1000 PSI (1/4" to 1"), 800 PSI (1 1/4" to 2") & 600 PSI (2 1/2" to 4")
Actuatable? Yes - features ISO Direct Mounting Pad
Manufacturer Mars

Approvals

The following certs and approvals are available to download for the Mars Series 33:

 CE Cert

 PED Cert

 ATEX Cert

 SIL Cert

 PTFE Cert
