Bray Series 20 Wafer Butterfly Valve - Stainless Steel Disc & EPDM Liner
SKU
BR2124
£204.00
4 - 5 days
Compatible file extensions to upload:
Key Features
- Trim 124
- Wafer Pattern
- Cast Iron Body
- Stainless Steel Disc
- EPDM Lined
- Sizes: 1" to 12"
- Temperature Range: -29°C to 121°C
- Pressure Rating: 7 Bar
- Lever or Gearbox Options
Details
Bray Series 20 Wafer Butterfly Valve - Stainless Steel Disc & EPDM Liner
The Bray series 20 resilient seated buttery valve surpasses the high standards required in food & beverage and chemical applications.
The valve features a wafer body design with flange locating holes, with a one-piece disc/stem that provides excellent shutoff protection (bubble-tight shutoff) and high Cv values with exceptionally long service life.
Bray’s peroxide cured EPDM (Ethylene Propylene Diene Monomer) seats have a higher resistance to abrasion, lower compression set, and higher temperature capabilities than sulphur cured seats. As a standard seat offering, Bray’s peroxide cured EPDM is the most universal and economical seat material used in our resilient seated butterfly valves. All of Bray’s peroxide cured EPDM seats are food grade.
KEY FEATURES:
- Trim 124
- Wafer Pattern
- Cast Iron Body
- Stainless Steel Disc
- EPDM Lined
- Sizes: 1" to 12"
- Temperature Range: -29°C to 121°C
- Pressure Rating: 7 Bar
- Lever or Gearbox Options
Technical Attributes
| Design | Wafer |
|---|---|
| Body Material | Cast Iron |
| Size | 1" (DN25), 1 1/2" (DN40), 2" (DN50), 2 1/2" (DN65), 3" (DN80), 4" (DN100), 5" (DN125), 6" (DN150), 8" (DN200), 10" (DN250), 12" (DN300) |
| Disc Material | Stainless Steel 316L |
| Liner | EPDM |
| Manufacturer | Bray |
